S4A DC motor controller

FTIS UNPAR
Free
1,000+ downloads

About S4A DC motor controller

DC motor 1 is connected to pin 10 for speed control and pin 12 for direction (CW / CCW)
DC motor 2 is connected to pin 11 for speed control and pin 13 for direction (CW / CCW)
Servo motor is controlled using pin 9
Bluetooth module uses HC-05 with 38400kBps
