ISP131001 is an autonomous low-power device for wireless acceleration, temperature and barometer detection and transmission. Overall size of the device is 12.5 x 25 x 3 mm. The host processor that handles the autonomous sensor application, the high level portion of the BLE protocol stack and communication with the sensors is a low power 32-bit MCU (ARM Cortex-M0 based), integrating 256 kB flash memory.
The complete device makes use of Insight SiP ISP130301 BLE module together with low power 3-axis accelerometer and temperature / barometer sensors connected to a primary button cell battery CR2032. The Freescale FXOS8700CQ 3-axis linear accelerometer and 3-axis magnetometer is used to detect acceleration and is combined with ST Micro LPS331AP temperature and barometer sensor.
The complete device makes use of Insight SiP ISP130301 BLE module together with low power 3-axis accelerometer and temperature / barometer sensors connected to a primary button cell battery CR2032. The Freescale FXOS8700CQ 3-axis linear accelerometer and 3-axis magnetometer is used to detect acceleration and is combined with ST Micro LPS331AP temperature and barometer sensor.
